Barrel ID & OD measurement and 3D inspection

Including rifling, lands, grooves, flank angles, chambers, cross holes. Same instruments measures mandrels, reamers, and drills.

Industry: Defense, barrel manufacturers

NOVACAMTM 3D metrology systems for barrel inspection offer:

  • Non-contact micron-precision measurements of barrel bores with IDs from 4 to 155 mm
  • 3D geometry measurement:
    • barrel bore ID & OD – diameter, roundness, cylindricity/conicity, straightness, runout, ID/OD concentricity, etc.
    • chambers – body, shoulder(s), neck, freebore, lead
    • rifling – lands and grooves, twist rate, variable twist rate, flank angles, etc.
  • Defect inspection and measurement
  • Roughness measurement
  • High acquisition speed of up to 100,000 3D point measurements per second

Rifle shooting range

The systems are easy to integrate in automated industrial inspection setups and provide comprehensive 3D measurement data for:

  • Automated user-configurable reports
  • SPC (statistical process control) monitoring of production
  • Gaining manufacture process insight that leads to process improvement
Microcam-3D-Tube-ID-Scanner
Video Player is loading.
Current Time 0:00
Duration -:-
Loaded: 0%
Stream Type LIVE
Remaining Time -:-

1x
    • Chapters
    • descriptions off, selected
    • captions off, selected

      Related links

      Download application notes:

      Contact us to discuss how Novacam 3D metrology systems can be integrated in your barrel production and inspection process.
